Cheap professional limestone/kaolin raymond vertical mill price

FOB Reference Price:Get Latest Price
$1,000.00 - $8,000.00 / Sets | 1 Set/Sets (Min. Order)
Power(W):
800kw
Model Number:
YGM4121
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Raymond Mill
Motor Type:
AC Motor
Capacity(t/h):
0.5-11TPH
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
SBM
Dimension(L*W*H):
9200*7250*9700mm
Weight:
16-46t
Certification:
ISO9001:2008, CE
Warranty:
12 months
After-sales Service Provided:
Engineers available to service machinery overseas
The Machines Classification:
raymond vertical mill
Color:
Yellow Iron Grey
After Sales Service:
The whole time
Spare Parts Supply:
Will Supply Any Time
Application:
Mining,Quarry,Chemical Industry and Construction
Test&Installation:
Professional Engineer Assigned
Delivery Detail:
30 Days
Pre sales service:
The whole time
Supply Ability
Supply Ability:
100 Set/Sets per Month raymond vertical mill
Packaging & Delivery
Packaging Details
1. small parts are wooden box package.
2. main engine nude packing, container, or upon customers requirement.
Port
Shanghai
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Video Description

Product Description



  Abundant Experience Wins Favors from Investors   - SBM



Welcome to inquire and know more details: Pls

Tel/Whatsapp/WeChat: +8615803820351
Email: hanbinglin (@) shibangcrusher.com







  Cheap professional limestone/kaolin raymond vertical mill price :



  limestone/kaolin raymond vertical mill is a kind of new-typed moderating-speed stone powder manufacturing machine, which is developed on the basis of RP. It is getting perfect by low consumption, low investment, environment friendly, small occupation area, and more efficient than the traditional mill.



limestone/kaolin raymond vertical mill parts

Raymond mill consists of motor, reducer, case, milling device, separator, outlet, coal feeding pipe, loading device, control box and sealing apparatus. The fittings are all of superior performance in the world at present.

  Cheap professional limestone/kaolin raymond vertical mill price application :

Raymond mill for mineral ore grinding plant
Raymond mill is mainly applied to the powder processing in mine ore mining plant. It can produce powder from more than 280 kinds of non-flammable and non-explosive mineral materials with Mohs hardness below 7 and humidity below 6%. The final size is between 0.613mm—0.044mm(100 mesh to 325 mesh). In south africa, raymond mill is also used for gold processing plant. Raymond grinder mill is the optimal milling equipment in electric power, kaolin, coal and cement industries.

Raymond mill for calcium carbonate powder production line
In the calcium carbonate grinding plant, raymond mill is mainly used for grinding stones into powder. For example, in the feldspar grinding plant, it is used to grind crushed feldspar into powder whose fineness meet the requirement. In this grinding process, it can also achieve drying effect.

Raymond mill for dolomite powder manufacturing

In the dolomite powder production line, it is used as stone powder grinding machine for crushing stones into powder with 100 mesh and 300 mesh. In India, raymond mill is used with crushing machine for grinding dolomite stones into powder.

  Cheap professional limestone/kaolin raymond vertical mill price main features :

  1. The whole raymond mill plant is a vertical structure of strong systematic characteristic, so it occupies small area. From crushing of raw material to grinding and packing is an independent production system.
  2. Compared with other milling plants, passing ratio achieves 99%, which other mill can not reach.
  3. Driving system of main frame adopts airtight gearing and pulley, drives smoothly and operates reliably.
  4. The electric control system is centralized controlled, so the automaticity is high, no people are needed in the operating room.
  5. Main parts of the whole plant are made from cast and steel of high quality. Such strict techniques insure the durability of whole plant.



  Cheap professional limestone/kaolin raymond vertical mill price technical data:



ModelYGM8314YGM9517YGM4121
Roller Quantity(pcs)345
Roller Diameter(mm)Φ270×140Φ310×170Φ410×210
Ring Diameter(mm)Φ830×140Φ950×170Φ1280×210
Rev 130103
Max.Feed Size202530
Discharging Size1.6-0.0451.6-0.0451.6-0.045
Capacity1.2-4.62.1-85-11
Machine Size5300×4100×52007100×5900×79009200×7250×9700



Cheap professional limestone/kaolin raymond vertical mill price manufacturer :



SBM is limestone/kaolin raymond vertical mill manufacturer in China, designed raymond mill by adopting German advanced milling technology, combining the characteristics of similar domestic products. SBM offer raymond mill with competitive price for sale for stone powder making industry in USA, Indonesia, Vietnam, India, Iran, Pakistan, Europe, Nigeria.











Project Case



   Mining mill and applications - Choose mining mill equipment






What is the mining ?



Mining is the earth's crust, or surface mining of mineral resources within the technology and science. Mining is the extraction of valuable minerals or other geological materials from the earth, usually from an ore body, vein or (coal) seam. Materials recovered by mining include base metals, precious metals, iron, uranium, coal, diamonds, limestone, oil shale, rock salt and potash. Mining of stone and metal has been done since pre-historic times. Modern mining processes involve prospecting for ore bodies, analysis of the profit potential of a proposed mine, extraction of the desired materials and finally reclamation of the land to prepare it for other uses once the mine is closed.



The mining mill applications in the mining industry

Mining mill also called mining grinding mill which is used widely in mining and grinding industry. Mining mills are mainly applied to the powder processing of mineral products in the industries of metallurgy, construction materials, chemical, and mining, etc. They can produce powder from various non-flammable and non-explosive mineral materials with Mohs hardness below 9 and humidity below 6%, such as quartz, feldspar, calcite, talcum, barite, fluoride, Xircom, cinder, white lime, concrete clinker, activated carbon, dolomite, granite, soft coal, coking coal, lignite, magnesia, chromium oxide green, gold ore, red clay, clay, kaolin, coke, coal Gangue, porcelain clay, kyanite, fluorspar, bentonite, medicinal stone linarite, diabase, pyrophyllite, shale red stone, emeraldite, basalt, gypsum, graphite, carborundun, heat insulating material, etc.

How to choose mining mill equipments in mining grinding industry

Mining mills are an essential part of ore mining equipments including raymond mill, ball mill, vertical roller mill, trapezium grinding mill, coarse powder mill, super thin grinding mill and so on.

Coarse powder mill is the ideal equipment to replace raymond mill, ball mill, and other trapezium mill which only process fine power materials. By being a component of closed production lines, it can produce various size products of better effect.

The whole machine of raymond grinding mill is collocated with jaw crusher, elevator, hopper, electromagnetic vibrating feeder, main unit, classifier, collector, cloth deduster and high-pressure blower.

Compared with the common raymond mill under the same power conditions, the capacity of the high pressure grinding mill can be increased by 10%; moreover, under the performance of high-pressure springs, the rollers grinding pressure on raw materials can be raised by 800-1200kgf.

Trapezium grinding mill is our newly mining machinery including MTM medium speed trapezium grinding mill and MTW series trapezium grinding mill. The mtm series has completely overcome traditional mill’s defect in application fields, capacity, fineness, energy consumption, service life, etc.MTW series grinding mill adopts bevel gear integral transmission, inner light-oil lubrication system, arc whirl tube and another proprietary technology.

Ball mill is an efficient tool for grinding many materials into fine powder. There are two ways of grinding: the dry process and the wet process. It can be divided into tabular type and flowing type according to different forms of discharging material.
